Description
The BD Alaris Syringe Module Microbore Set with pressure sensing disc is designed for precision infusion in critical care settings. With a 60-inch microbore tubing, fixed male luer lock, and integrated monitoring capabilities, it supports early occlusion detection while minimizing medication waste.
- Integrated Pressure Sensing Disc – Enhances safety by enabling early occlusion detection and controlled infusion management.
- Microbore Tubing (60") – Offers a 0.7 mL priming volume for low waste, supporting high-accuracy drug delivery.
- Fixed Male Luer Lock – Ensures a secure, leak-resistant connection compatible with standard syringe modules.
- Slide Clamp Included – Facilitates safe disconnection and line management during setup and transport.
- Sterile and DEHP-Free Fluid Path – Designed for patient safety and regulatory compliance in infusion therapy.
Precision Infusion with Built-In Pressure Monitoring for Enhanced Safety
The BD Alaris Syringe Module Microbore Set is a sterile, DEHP-free administration set built for use with BD Alaris syringe modules. It features an integrated pressure sensing disc that supports accurate infusion pressure monitoring—helping prevent bolus release during occlusions. With a priming volume of only 0.7 mL, the microbore tubing minimizes waste, making it ideal for precise drug delivery in high-acuity environments. This long extension set is optimal for intensive care, anesthesia, and other critical applications.
Features and Benefits
Advanced Infusion Monitoring
-
Pressure Sensing Disc – Offers real-time occlusion detection, improving patient safety and infusion control.
Low-Volume, High-Accuracy Delivery
-
Microbore Tubing (60 inches) – Provides minimal 0.7 mL priming volume, reducing drug waste and enhancing delivery accuracy.
Secure, Standardized Connection
-
Fixed Male Luer Lock – Ensures secure fit and compatibility with most infusion systems.
Convenient Line Management
-
Slide Clamp – Allows quick occlusion for safe handling and line access without disconnection.
Safe, Sterile Design
- DEHP-Free Fluid Path – Promotes biocompatibility for sensitive patients.
- Sterile Packaging – Ensures clinical cleanliness and infection control readiness.
Product Specifications
Tubing & Connectors
- Tubing Type: Microbore
- Length: 60 inches (152 cm)
- Priming Volume: 0.7 mL
- Connector Type: Fixed male luer lock
- Clamp Type: Slide clamp
- Y-Sites, Valves, Manifolds: None
Material & Compliance
- Fluid Path: DEHP-free, sterile
- Latex Content: Contains natural rubber latex
- Stopcock, Filters, T-Connectors: None
- Sterility: Fluid path sterile
Packaging
- Unit of Measure: Per case
- Quantity: 100 units per case
- Case Dimensions: 16 in x 9.875 in x 8 in
- Weight: 4.7 lb (2.13 kg)
Why Choose BD Alaris Syringe Module Microbore Set Over Other Options?
The BD Alaris Syringe Module Microbore Set uniquely combines precision drug delivery with built-in pressure monitoring—making it a reliable choice for critical care. Its microbore design supports efficient delivery, while the secure luer lock and slide clamp ensure safe handling and line control.
- Advanced pressure monitoring for occlusion detection
- Low-volume microbore tubing minimizes medication waste
- Secure, leak-resistant luer lock connection
- Slide clamp simplifies line occlusion and disconnection
- DEHP-free, sterile fluid path enhances patient safety
Frequently Asked Questions (FAQs)
What is the priming volume of the BD Alaris Syringe Module Microbore Set?
The priming volume is 0.7 mL, supporting efficient drug delivery with minimal waste.
Does the set include pressure monitoring?
Yes, it features a built-in pressure sensing disc that supports early occlusion detection.
Is the tubing sterile and DEHP-free?
Yes, the fluid path is sterile and free of DEHP for patient safety.
What type of connector does this set use?
It includes a fixed male luer lock for secure and standard device compatibility.
Can I use this set with BD Alaris syringe modules?
Yes, it is specifically designed for use with BD Alaris syringe pumps.
