Description
The Conquest 40 PTA Dilatation Catheter is designed for precision dilation of resistant lesions in peripheral arteries. With balloon diameters ranging from 4 mm to 12 mm and lengths up to 100 mm, this ultra non-compliant catheter provides consistent sizing under extreme pressures—up to 40 ATM—making it ideal for challenging vascular interventions.
- Ultra High-Pressure Performance – Rated up to 40 ATM to effectively treat fibrotic or calcified lesions.
- True-to-Size Dilation – Maintains accurate diameter at nominal and rated burst pressures.
- Tapered Tip Design – Supports smooth lesion entry and excellent trackability.
- .035" Guidewire Compatibility – Standard over-the-wire integration across all sizes.
- Single-Use, Sterile – Packaged individually for aseptic, controlled procedural use.
Built for High-Stakes Peripheral Interventions
The Conquest 40 catheter offers the highest pressure rating in BD's PTA portfolio. It is tailored for physicians requiring precise dilation control, especially when treating complex lesions. Its design ensures balloon integrity without diameter drift, even at burst pressure levels, making it a critical tool for vascular access maintenance and PAD treatment.
Features and Benefits
Ultra Non-Compliant Design
- Maintains Diameter at High Pressure – Ensures consistent performance up to 40 ATM.
- Reduces Overdilation Risk – Avoids vessel trauma due to unintended balloon expansion.
Optimized Trackability and Control
- Tapered Tip – Improves lesion access and minimizes resistance during delivery.
- Syringe-Compatible Inflation – Eliminates the need for specialized inflation equipment.
Broad Clinical Utility
- Available in 4 mm to 12 mm Diameters – Supports a wide range of lesion sizes.
- Lengths from 20 mm to 100 mm – Allows tailored dilation across various anatomies.
- 75 cm Shaft – Facilitates access to deep peripheral vessels.
Product Specifications
Balloon Dimensions
- Diameter Options: 4 mm, 5 mm, 6 mm, 7 mm, 8 mm, 9 mm, 10 mm, 12 mm
- Length Options: 20 mm, 40 mm, 60 mm, 80 mm, 100 mm
Catheter Details
- Shaft Length: 75 cm
- Nominal Pressure: 8 ATM
- Rated Burst Pressure: 40 ATM
- Sheath Compatibility: 6 F
Packaging
- Unit of Measure: 1 catheter per package
- Sterility: Sterile, single-use
- Guidewire Compatibility: 0.035"
Why Choose Conquest 40 PTA Catheter Over Other Options?
The Conquest 40 stands out for its unmatched pressure tolerance and precision sizing. Designed for difficult-to-treat vascular lesions, it delivers superior performance where standard balloons may fail.
- Ideal for calcified, fibrotic, or restenotic lesions
- True-to-size dilation reduces the need for re-inflation
- Syringe-based inflation system improves workflow efficiency
- Tapered tip ensures smooth lesion entry and positioning
Frequently Asked Questions (FAQs)
What conditions is the Conquest 40 catheter used for?
It is indicated for peripheral angioplasty, particularly in calcified or resistant stenotic lesions.
What pressure range does the balloon support?
It supports 8 ATM nominal and 40 ATM rated burst pressure.
Can this catheter be inflated with a standard syringe?
Yes. It is compatible with standard syringes, eliminating the need for inflation devices.
Is this catheter compatible with a 0.035" guidewire?
Yes, it is fully OTW-compatible with 0.035" guidewires.
Are multiple balloon lengths available?
Yes, lengths range from 20 mm to 100 mm, with 34 variants currently listed.
